The Nexos 4.0 software from Eleven Dynamics enables automated measurement processes to be simulated and managed in a digital twin. This means that any robot, sensor and cell configuration as well as external software can be supported. Users do not need to know different software or interfaces, just one.

The laser photothermal technology advanced by Enovasense – a Precitec Optronik subsidiary – measures coating thicknesses of all types (e.g. metal, ceramics, paint, polymers, adhesives, etc.) on any carrier material. This makes it possible to precisely measure the thickness of opaque layers as well as nanometer-thin coatings.

The lock-in principle enables the extraction of the smallest signals from very noisy environments. With the HeliCam C4, Heliotis is also making the process accessible for industrial cameras. A camera that integrates this technology at the pixel level can almost completely suppress sources of interference such as constant background or 1/f noise.

With the VisionPort, Invisium has developed a multifunctional scanner that captures euro pallets, mesh boxes or crates in countless variations on-the-fly in just a few seconds and achieves an identification rate of greater than 98%. An AI reconstructs holistic information from incorrect signals if something is scratched or covered under foil.

Photoneo introduces the 3rd generation of Ambient Light Suppression technology to enable 3D scanning even under the most demanding lighting conditions. The technology not only ensures high scanning quality in direct sunlight, but also for large objects with shiny surfaces, such as cars.

The Poly Robot Automated Fixture System (Prafs) from Protos 3D automates the virtual clamping of Zeiss Metrology’s ScanBox technology. Thousands of different components are held on a flexible device. The parts are changed and positioned automatically in seconds without any mechanical retooling.

Thanks to Smart Vision Lights’ hidden strobe technology, LEDs can trigger themselves internally thousands of times/sec, producing a nearly continuous light source. When the light is triggered synchronously with the camera to take a picture, the hidden flash pulses stop and the programming pulse for the camera is executed.

The measuring device from Tenta Vision works according to the principle of laser interferometry and detects stiffness inhomogeneities in a deformation analysis. Components are stressed by an energy input and are caused to deform on the nm scale. This is recorded as a video and visualized using real-time evaluation algorithms.

The 3D V-Rox system from voidsy is a compact and smart photothermal tomography system. Based on active thermography, the device determines the 3D geometry of hidden material and component defects. This makes it possible to determine absolute defect sizes, as well as the lateral defect size or defect depth.

The Abis III optical sensor with multi-color technology (six color cameras, 180 LEDs) from Zeiss IMT has a high error detection rate, an image recording frequency of up to 20Hz and a high and consistent depth resolution. The automated inline surface inspection for car bodies and pressed sheet metal parts detects defects at top speed.
